title: 'Headless WordPress & Next.js on Kubernetes: Page Revalidation and CDN Invalidation'
date: '2023-03-26'
tags: ['next.js', 'wordpress', 'kubernetes']
draft: false
featuredImage: blog/robot-person-at-a-desk-weird.jpeg
summary: >
  If you're looking to revalidate a Next.js page automatically after a WordPress post update, read
  on! The technique can be applied to any back-end using Next.js for the front-end, hosted in a
  Kubernetes cluster.
---

<Aside>
  Update 2023/04/12: This article in its current state only addresses 75% of the problem. An update
  is forthcoming to include the process to clear the CDN of the relevant NextJS .json data files.
</Aside>

## The Problem

The problem faced is not unique: following a post update on back-end, we want to have the front-end
automatically _revalidate the page_ in order to cache the latest content in the Next.js page cache.
Then, if we're using a CDN on top of that, we want to automatically purge that same path in the CDN
as well.

## The Solution

This solution is based on the premise that the front-end _and_ back-end are both hosted in the same
Kubernetes cluster. With this setup, the front-end and back-end pods can communicate directly
without needing to leave their local network.

If your setup does not have the front-end and back-end pods sharing the same cluster, there _is_ a
workaround, although it's not quite as efficient.

In a nutshell, here's how we can handle this issue if both front-end and back-end are in the same
cluster:

**When a post is updated in the back-end, we need to trigger the following:**

1. Make a request to Kubernetes to get a list of all front-end pod IP addresses.
2. Send simultaneous async Next.js API requests to _each_ front-end pod to
   [revalidate a path.](https://nextjs.org/docs/basic-features/data-fetching/incremental-static-regeneration#on-demand-revalidation)
3. If all requests return successfully, send one final request to the CDN to clear the path from CDN
   cache.

If the front-end and back-end are _not_ in the same cluster, here are similar steps which can
accomplish the same:

**When post is updated in back-end, we'd need to:**

1. Make a _single_ Next.js API request to the front-end to revalidate a path.
2. The receiving Next.js pod requests a list of its neighboring front-end pod IPs from Kubernetes.
3. The Next.js pod sends simultaneous async requests to all neighboring front-end pods to revalidate
   the same path(s).
4. If all requests return successfully, the pod sends one final request to the CDN to clear the path
   from CDN cache.

As you can see, they're similar approaches, but the 2nd version requires an additional network
request, which can cause the entire process to take _slightly_ longer.

For this article, we'll focus on the **first** approach.

**Here we go!**

## Step 1: Set up a `kubectl` "Sidecar" for Kubernetes

First, set up a
["sidecar"](https://kubernetes.io/docs/tasks/run-application/access-api-from-pod/#using-kubectl-proxy)
pod whose sole responsibility is to run
[kubectl proxy](https://kubernetes.io/docs/tasks/extend-kubernetes/http-proxy-access-api/#using-kubectl-to-start-a-proxy-server).

I set up `kubectl proxy` to run on port **8001**, which is closed to the rest of the internet from
Kubernetes. This port would _only_ be used by local neighboring pods to make Kubernetes API
requests.

This sidecar pod doesn't need many resources; it can be set quite low. Perhaps 0.5 vCPU and 0.5GB
memory.. experiment and find what works best for your system.

<Aside>

### But why can't I use a PHP package to get the Kubernetes pod list?

When I was first exploring this problem, I attempted to use the
[AWS PHP SDK](https://docs.aws.amazon.com/aws-sdk-php/v3/api/class-Aws.EKS.EKSClient.html). The SDK
does have functions to describe clusters and node groups, but it couldn't _list **pods** and their
associated details_. This was a problem, and I needed to come up with an alternate solution.

> Note: If you do find a PHP package that's well-supported and can list Kubernetes pods within AWS,
> please share! If something like this is available, then the "sidecar" is not required.

</Aside>

### The "Sidecar" Code

The `kubectl proxy` "sidecar" pod is based on a Docker image. Here's a simplified, generic version
of what I used:

<CodeHeader>kubectl.dockerfile</CodeHeader>

```bash
# Using AWS CLI as base image because as part of the build process,
# we need to use AWS credentials to gain access and set the default
# kubectl cluster.
FROM amazon/aws-cli:latest

# Replace with your specific info:
ARG AWS_ARN=arn:aws:eks:us-east-1:1234567890:cluster
ARG CLUSTER_NAME=the-cluster-name
ARG AWS_REGION=us-east-1
ARG ARCH=arm64

# 1.24.x was throwing an error during build. Using 1.23.6 for now.
ARG KUBECTL_VERSION=1.23.6

# Provide these args securely during the build command via --build-arg
ARG AWS_ACCESS_KEY_ID
ARG AWS_SECRET_ACCESS_KEY
ENV AWS_ACCESS_KEY_ID=${AWS_ACCESS_KEY_ID}
ENV AWS_SECRET_ACCESS_KEY=${AWS_SECRET_ACCESS_KEY}

# Install kubectl dependency. There is code in the back-end which needs to list and ping
# specific running pods. In order to do this, we need to use the kubectl API. The reason for this,
# is that the latest PHP SDK for AWS does not appear to be able to list pods itself.
RUN curl -LO "https://dl.k8s.io/release/v${KUBECTL_VERSION}/bin/linux/${ARCH}/kubectl"
RUN install -o root -g root -m 0755 kubectl /usr/local/bin/kubectl

# Configure AWS EKS and kubectl for the specific cluster.
RUN aws eks --region ${AWS_REGION} update-kubeconfig --name ${CLUSTER_NAME}
RUN kubectl config use-context ${AWS_ARN}/${CLUSTER_NAME}

# Copy kubectl proxy startup script so it can be used in container.
COPY kubectl.sh /usr/src/
RUN chmod +x /usr/src/kubectl.sh

ENTRYPOINT [ "sh", "/usr/src/kubectl.sh" ]
```

The contents of `kubectl.sh` startup script is as follows:

<CodeHeader>kubectl.sh</CodeHeader>

```bash
#!/bin/bash

# This opens up kubectl access via API endpoint for the kubectl pod.
# Attempted access to port 8001 (where kubectl proxy serves from) will be
# allowed from any local host with access to port 8001 in the cluster.
# Specific paths can be allowed, and accepted hosts can be further restricted.
kubectl proxy --address 0.0.0.0 \
    --accept-hosts '.*' \
    --accept-paths '^/api/v1/namespaces/default/pods*'
```

When this `kubectl` (name can vary or be customized, of course) pod gets built and deployed to the
Kubernetes cluster, we should have a `kubectl` pod available locally which can be accessed via HTTP.
For example, to get our list of pods within the cluster, we could make a `GET` request to:
`http://kubectl:8001/api/v1/namespaces/default/pods`

## Back-end (WordPress)

With the sidecar now set up, we can prepare the back-end code for WordPress in PHP. For brevity, I'm
going to skip all the fundamental error handling and scaffolding required to write some proper
classes and tests to support this. Let's skip straight to the main points.

Here's a helper function that we'll use to fetch a list of local pod IP addresses:

```php
function get_front_end_pod_ip_addresses() {
  // Don't forget to check for errors, handle exceptions and validate data!
  $front_end_service_name = "your-front-end-service-name";

  // Fetch a list of pods from the kubectl sidecar container.
  $kubectl_api_result      = wp_remote_get( "http://kubectl:8001/api/v1/namespaces/default/pods" );
  $kubectl_api_result_body = wp_remote_retrieve_body( $kubectl_api_result );
  $pods_list = json_decode( $kubectl_api_result_body );

  // Prepare a list of Kubernetes Pod IP addresses.
  $pod_ip_addresses = array();

  // Overrides the pod IP for local development purposes.
  // Value can be something like: host.docker.internal:3000
  // We can use this value to make an actual call to the front-end
  // Next.js development environment, for example.
  $pod_ip_address_override = getenv( 'POD_IP_ADDRESS_OVERRIDE' );

  foreach ( $pods_list->items as $pod ) {
    if ( str_contains( $pod->metadata->name, $front_end_service_name ) ) {
      // If $pod_ip_address_override is populated, we'll use that specific IP for each entry.
      // We allow the function to process this far rather than returning these values early,
      // so that we can be sure that the whole process works as intended.
      $pod_ip_addresses[] = $pod_ip_address_override ? $pod_ip_address_override : $pod->status->podIP . ':3000';
    }
  }

  return $pod_ip_addresses;
}
```

This helper function is used to retrieve our list of local Kubernetes front-end pod IP addresses, to
which we'll _then_ send
[Next.js on-demand revalidation requests.](https://nextjs.org/docs/basic-features/data-fetching/incremental-static-regeneration#on-demand-revalidation)

Since this on-demand revalidation process is well-documented in the previous link, I will not go
into details on setting that up here.

See below for a function to leverage the front-end pods' on-demand ISR revalidation API:

```php
function revalidate_nextjs_cache( $relative_url = '' ) {
  // Don't forget to check for errors, handle exceptions and validate data!

  // Here's our helper in play:
  $pod_ip_addresses = get_front_end_pod_ip_addresses();

  $next_api_token = getenv( 'NEXT_API_TOKEN' );

  // Prepare an array of POST requests to send asynchronously.
  $requests = array();
  foreach ( $pod_ip_addresses as $pod_ip_address ) {
    $requests[] = array(
      'url'  => "http://$pod_ip_address/api/revalidate?" . http_build_query(
        array(
          "secret" => $next_api_token,
          "path"   => $relative_url,
        )
      ),
      'type' => 'POST',
    );
  }

  // https://developer.wordpress.org/reference/classes/requests/request_multiple/
  // Note: it seems this Requests class is deprecated. Should be updated to use
  // the new version...
  $responses     = \Requests::request_multiple( $requests );
  $response_data = array();

  // Loop through each response and ensure all of them can be properly decoded.
  /** @var Requests_Response|Requests_Exception_Transport_cURL $response */
  foreach ( $responses as $response ) {
    if ( is_a( $response, 'Requests_Exception_Transport_cURL' ) ) {
      // Handle your exceptions...
      return new \WP_Error( 'exception', __( $error_message, 'your-text-domain' ) );
    }

    if ( is_a( $response, 'Requests_Response' ) ) {
      $response_data[] = json_decode( $response->body );
    }
  }

  // Loop through each decoded response to ensure they've all succeeded to revalidate.
  foreach ( $response_data as $data ) {
    // If at least one of the revalidation attempts fails, the entire process fails.
    if ( ! isset( $data->revalidated ) || true !== $data->revalidated ) {
      $error_message = 'Unable to revalidate URL. Response: ' . wp_json_encode( $data ) . ' - URL: ' . $relative_url;
      return new \WP_Error( 'failed-to-revalidate', __( $error_message, 'your-text-domain' ) );
    }
  }

  // Success!
  return true;
}
```

**Note:** It should be fairly easy to modify this code to support an array of paths instead of a
single path! This could be helpful to revalidate pages in bulk, say during a bulk post update.

Finally, let's stitch these together to call this when a post is updated:

```php
function post_updated_handler( $post_id, $post_after, $post_before ) {
  // Don't forget to check for errors, handle exceptions and validate data!

  if ( defined( 'REST_REQUEST' ) && REST_REQUEST ) {
    // We only want to revalidate the cache on the final save action, so skip this one.
    return;
  }

  if ( defined( 'DOING_AUTOSAVE' ) && DOING_AUTOSAVE ) {
    // There is no need to revalidate the cache for an autosave, either. Skip it.
    return;
  }

  if ( 'publish' !== $post_after->post_status ) {
    // Do not clear caches for drafts, private, future, etc.
    // If we want to clear caches when a post is moved from one state to another, we'll
    // need to leverage the transition_post_status action:
    // https://developer.wordpress.org/reference/hooks/transition_post_status/
    return;
  }

  // Retrive only the /relative/url/to/page/ (strip the domain).
  $relative_url = str_replace( 'https://yourdomain.com/', '', get_the_permalink( $post_id ) );

  // Let's revalidate this relative URL in front-end:
  $next_result = revalidate_nextjs_cache( $relative_url );

  // If the NextJS revalidation attempt fails, there's no need to attempt
  // to invalidate the CDN. Exit early.
  if ( is_wp_error( $next_result ) ) {
    return $next_result;
  }

  $invalidation_id = invalidate_url_in_cdn( $relative_url );

  // We could use this ID to link directly to the invalidation in AWS.
  return $invalidation_id;
}

add_filter( 'post_updated', array( $this, 'post_updated_handler' ), 10, 3 );
```

**But wait! What is this `invalidate_url_in_cdn()` function??**

See below. This one is based on AWS CloudFront, but you can modify the function to invalidate any
CDN with API access.

```php
// https://docs.aws.amazon.com/sdk-for-php/v3/developer-guide/getting-started_installation.html
use Aws\CloudFront\CloudFrontClient;
use Aws\Exception\AwsException;

function invalidate_url_in_cdn( $relative_url = '' ) {
  // Don't forget to check for errors, handle exceptions and validate data!

  // Set this any way you'd like. This is just an example.
  $distribution_id = getenv( 'CLOUDFRONT_DISTRIBUTION_ID' );

  // Set up the CloudFront client via AWS PHP SDK.
  $cloudfront_client = new CloudFrontClient( array(
    'version' => 'latest',
    'region'  => 'us-east-1',
  ) );

  try {
    // Generate a unique md5 string. Or set whatever you would like.
    $caller_reference = md5( time() );

    $result = $cloudfront_client->createInvalidation(
      array(
        'DistributionId'    => $distribution_id,
        'InvalidationBatch' => array(

          'CallerReference' => $caller_reference,
          'Paths'           => array(
            'Items'    => array( $relative_url ),
            // Can be modified to use count( $urls ) if this function accepts an array of URLs.
            'Quantity' => 1,
          ),
        ),
      )
    );

    if ( isset( $result['Invalidation'] ) && isset( $result['Invalidation']['Id'] ) ) {
      // Success! Return the ID string.
      return $result['Invalidation']['Id'];
    }

    // Uh oh, couldn't find the invalidation ID...
    $error_message = 'CloudFront Invalidation ID not found for attempted invalidation of ' . $relative_url;
    return new \WP_Error( 'failed-to-invalidate-cdn', __( $error_message, 'your-text-domain' ) );

  } catch ( AwsException $exception ) {
    // Welp, we failed.
    return new \WP_Error( 'aws-exception', __( $exception->getMessage(), 'your-text-domain' ) );
  }
}
```

## Conclusion

That's the gist of it! Now when you update a post, page, etc. in WordPress, the front-end pods
should revalidate the page, followed by a CDN cache clear on successful revalidation.

If you have any questions, or run into any issues, please feel free to ping me on Twitter:
[@missionmikedev](https://twitter.com/missionmikedev) or find me on
[LinkedIn.](https://www.linkedin.com/in/michaeldinerstein/) I can't promise an answer, but I can
promise a response :)


MissionMike.dev

Headless WordPress & Next.js on Kubernetes: Page R...

Tags & Categories
